销售Temptronic TP04300A-8C32-9 热流仪

浏览次数:238

产品参数

选件 是否计量 发货周期 保修时间 成色
5天 90天 8成新
所在地 机身号 状态 资料下载
- 完好
更新日期:2024-12-31
联系电话:0755-86016691

* 产品描述

产品描述:

Temptronic Thermostream TP04300A 高功率、全功能气流系统可快速、精确地为小型和大型设备、模块、PCB 和组件提供受控温度,以进行热循环、分析和测试。温度范围*:-80° 至 +225°C。

产品特点:

  • 气流:高容量 9 l/s (18 scfm) 连续气流优化了温度转换率和吞吐量。
  • 典型温度转变率:
    • -55° 至 +125°C:约 7 秒
    • +125° 至 -55°C:约 20 秒
  • 温度控制:空气或专利 DUT 双回路直接控制在 DUT 外壳上,精度为 ±0.1°C
  • DUT 传感器端口:四个:内部二极管、T 型或 K 型热电偶和 100 欧姆 RTD
  • 温度设定、显示及分辨率:±0.1℃
  • 温度精度:1.0°C(根据 NIST 标准校准)
  • 远程接口端口:四个:IEEE-488、RS232C、SOT/EOT/SFF、以太网。
  • 用户可通过前面板彩色触摸屏或远程接口进行控制

详细信息

Product Description:

The Temptronic Thermostream TP04300A high power, full featured airstream system delivers controlled temperature with speed and precision to small and large devices, modules, PCBs and assemblies for thermal cycling, profiling and testing. Temperature Range*: -80° to +225°C.

Features:


  • Airflow: High capacity 9 l/s (18 scfm) continuous airflow optimizes temperature transition rate and throughput.
  • Typical Temperature transition rate:
    • -55° to +125°C: approximately 7 seconds
    • +125° to -55°C: approximately 20 seconds
  • Temperature Control: Air or Patented DUT Dual Loop directly at the DUT case to ±0.1°C
  • DUT Sensor Ports: Four: Internal Diode, Type T or Type K thermocouple, and 100 ohm RTD
  • Temperature set, display and resolution: ±0.1°C
  • Temperature Accuracy: 1.0°C ( calibrated to NIST standard)
  • Remote interface ports: Four: IEEE-488, RS232C, SOT/EOT/SFF, Ethernet.
  • User Control at Color Touch-screen at front panel or via remote interface
