Desky DK-2200-MF is a high-magnification fiber optic end-face inspection instrument that complies with IEC/JPC international standards and can also be customized to higher standards. It is suitable for visual inspection of end-faces of various fiber optic connectors (male) and module sockets (female), balancing top loss, chamfering and 3D functions. With reliable overall performance, it has outstanding advantages in ultra-high definition and fast auto-focus, making it the preferred device for end-face inspection and acceptance of 5G standard optical devices.
-
Inspection function: Supports single/multi-core male/female end-face inspection, 200X magnification
-
Resolution: 0.75μm
-
Field diameter: 40mm
-
Adjustment: Max 9×9mm (single-core), max X8mm/Y4mm (multi-core); supports auto/manual adjustment and XY axis adjustment
-
Display & power supply: 8.0-inch TFT HD display, powered by DC 12V/0.8A
-
Optional functions: USB connection to computer, Pass/Fail test software, memory card, large-capacity lithium battery, etc.
-
Specifications: Dimensions 295mm×200mm×255mm, weight 2KG; anti-static; operating temp -10℃~60℃, storage temp -20℃~70℃
