Product Overview:
The Haito HZK-1000 series is a set of industrial automation intelligent controllers, specially designed for complex industrial environments. It is widely applied in intelligent manufacturing, energy management, mechanical control and other fields. This series boasts core advantages such as high performance, modular expansion and strong compatibility, and supports various industrial protocols and customized requirements.
Product Features:
Hardware performance
Processor: Utilizes multi-core ARM Cortex or industrial-grade x86 CPU, with a clock frequency of ≥ 1GHz, and supports real-time operating systems (such as RT-Linux or FreeRTOS).
Storage: Built-in Flash (≥ 8GB) + RAM (≥ 2GB), supports SD card for data expansion storage.
Protection level: IP65/IP67 protection, metal casing, resistant to vibration, dustproof and moistureproof, suitable for a wide temperature range of -30℃ to 70℃.
2. Modular Expansion
I/O Module: Supports hot swapping, optional:
Digital input/output (16 to 32 channels)
Analog quantity (4~20mA/0~10V, 12~16 bit accuracy)
High-speed counter (HSC), PWM output, etc.
Communication expansion: Optional RS-485, CAN bus, EtherCAT, Profinet and other modules can be equipped.
3. Communication and Networking
Built-in protocols: Modbus RTU/TCP, OPC UA, MQTT, HTTP/HTTPS.
Network interface: Dual Gigabit Ethernet, 4G/5G (optional), Wi-Fi 6 (available in some models).
Cloud platform integration: Supports Alibaba Cloud IoT, AWS IoT, and private cloud deployment, enabling remote monitoring and data analysis.
4. Control and Programming
Development Environment:
Supports the IEC 61131-3 standard (languages such as LD, FBD, ST, etc.).
Provide secondary development APIs (C/C++, Python scripts).
Advanced Features:
Multi-axis motion control (supports EtherCAT servo drives).
PID closed-loop regulation and temperature control algorithm library.
