Description:
The M9505A AXIe 5-slot chassis of Agilent (now Keysight Technologies) is a modular chassis specifically designed for high-performance test and measurement applications. Support the AXIe (AdvancedTCA Extensions for Instrumentation and Test) standard.
The Agilent M8190A arbitrary waveform generator can provide reliable and repeatable measurements through precise signal simulation. High dynamic range and excellent vertical resolution assure you that you are testing the device, not the signal source. The Agilent M8190A arbitrary waveform generator can fully optimize the output to match your application. Its function can ensure flexible modification to adapt to new distortion requirements by simply adjusting the waveform itself. Its 2 GSa memory, combined with advanced sorting functions, enables you to create complex signal scenarios and use the memory efficiently and effectively. The 5 GHz modulation bandwidth provides you with sufficient space to test and handle the next-generation modulation schemes.
Features:
Modular design
It offers 5 AXIe slots (1 system slot + 4 peripheral slots), supporting a hybrid configuration of AXIe and partially compatible PXIe modules.
The system Slot (Slot 1) is used to install the AXIe system controller module (such as M9502A), and other slots can be used to install measurement or signal generation modules.
High-performance architecture
Based on the AXIe standard (ATCA extension), it provides high-bandwidth and low-latency communication capabilities, suitable for applications such as high-speed data acquisition, semiconductor testing, and wireless communication.
Supports PCIe Gen2/Gen3 links, with a bandwidth of up to 8 GB/s (bidirectional) for each peripheral slot.
Heat dissipation and Power Supply
It integrates an efficient heat dissipation system and supports forced air cooling to ensure the stable operation of high-power modules (such as power amplifiers or high-speed digitizers).
It provides a total power output of up to 1000W to meet the high power consumption requirements of multiple modules.
Compatibility
Compatible with AXIe 1.0 and some PXIe modules (adapter required), and can work in coordination with other Keysight test devices (such as PXIe chassis).
Support SCPI and IVI drivers to simplify system integration.
Application scenarios
It is applicable to scenarios such as automated test equipment (ATE), R&D laboratories, and production testing, and is particularly suitable for applications that require high channel numbers or high throughput (such as 5G, millimeter wave, and power electronics testing).
Precision AWG with 2 DAC Settings:
14-bit resolution, up to 8 GSa/s
12-bit resolution, up to 12 GSa/s
High-speed arbitrary waveform generator
The variable sampling rate ranges from 125 MSa/s to 8/12 GSa/s
Spurious dynamic range (SFDR) up to 80 dBc (typical value)
Harmonic distortion (HD) up to -72 dBc (typical value)
Arbitrary waveform memory with up to 2 GSa per channel and advanced sorting function
Analog bandwidth 5 GHz (direct DAC output)
