Product Description:
6654A high performance DC power supplies offer speed and accuracy for test optimization. The single output, 500W GPIB 665x series provide fast, low-noise outputs; analog control of output voltage and current; and fan-speed control to minimize acoustic noise.
The 540W, single output 6654A is a fast and flexible power supply or automated testing, and is designed to increase test throughput with fast up- and downprogramming times.
Features：
Output Ratings
-
Output voltage: 0 to 60 V
-
Output current (40°C): 0 to 9 A
-
Maximum current (50°C/55°C): 8.1 A/7.7 A
Programming Accuracy at 25°C ±5°C
-
Voltage 0.06% + 26 mV
-
Current 0.15% + 8 mA
Ripple & Noise from 20 Hz to 20 MHz
-
Voltage rms: 500 µV
-
Peak-to-Peak: 5 mV
-
Current rms: 3 mA
