Product Overview:
The Agilent 81571A optical attenuator offers two or four attenuator channels for multimode fiber devices, respectively, and offers 50 µm or 62.5 µm fiber ports. By monitoring the output power, accurate and stable power Settings can be achieved at any input power. The convenient bias parameter allows the set power to match the signal behind other optical devices in the path of the test device.
Features:
Measuring function: Attenuator
Setup time: 20 ms attenuation, 100 ms power
0.1 ~ 1000 dB/s attenuation conversion speed (optional)
+23 dBm input power
≤ 1.2dB insertion loss
Measuring function: power meter
Wavelength range: 1260-1640 nm
Power range: -80 ~ +10 dBm
Polarization correlation: <0.01 dB
