浏览次数：621
| 选件 | 是否计量 | 发货周期 | 保修时间 | 成色 |
|---|---|---|---|---|
| 否 | 1-4天 | 12- | 全新 | |
| 所在地 | 机身号 | 状态 | 资料下载 | |
| 深圳市 | 完好 |
产品描述：
GNS5000模拟系统可以提供BeiDou 、 GPS 、Galileo、GLONASS信号。可以为广泛的各类开发和集成工作提供卫星信号。
特性
product description:
GNS5000 analog system can provide BeiDou, GPS, Galileo, GLONASS signals. Can provide satellite signals for a wide variety of development and integration tasks.
characteristic：
* Support multiple constellations and multiple frequencies (GPS, GLONASS, GALILEO, BEIDOU, SBAS)
* Using COTS hardware can simulate hundreds of satellites in real time
* Integration generates high dynamic interference (GNSS & non GNSS)
* User-defined waveforms (Chirp, CW, BOC, BPSK, AWGN & pulse modulations combination)
* 1000Hz simulation iteration rate
* High-end performance (precision, resolution, ultra-high dynamic motion)
* Powerful automation and easy-to-understand APIs (Python, C #, and C ++ open source)
* Differential GNSS and multi-vehicle simulation
* HIL supports real-time, running scene reconstruction
* 60DoF receiver and transmitter track / LEO-GEO running track
* Multipath support
* Ability to import files in multiple formats (CSV, KML, NMEA, etc.)
* GNSS satellite operation modification and customized fixed position
* Additional ramps to infinite pseudorange
* Scene editor with full map
* Flexible licensing and unmatched upgrade capabilities
