Product Description:
The Keysight MSOX3104A is a four-channel model in the InfiniiVision 3000 X series. Designed with breakthrough technology, this upgradeable oscilloscope delivers superior performance and functionality. Its unique 5-in-1 design offers more uses for the same budget
Features:
One million waveform update rates per second
MegaZoom IV Smart Memory technology
8.5-inch WVGA display
Optional segmented memory
Keysight MSOX3104A (Agilent) specifications include:
Bandwidth (-3 dB) : 1 GHz
Calculated rise time (10-90%) : ≤ 450 ps
Input channel:
4 analog channels
16 digital channels
Maximum sampling rate:
5 GSa/s Half-channel
Full channel 2.5 GSa/s
Maximum storage depth:
Standard 2 Mpts
Optional 4 Mpts
Selectable segment memory
