Product Overview
The Keysight DSOX4022G is a dual-channel digital oscilloscope in the InfiniiVision 4000G X series, designed specifically for embedded system development, low-speed signal integrity analysis, and basic RF testing. With a 200 MHz fixed bandwidth and a 5 GSa/s full-channel sampling rate, combined with 4 Mpts deep storage (shared by all channels) and a 12-bit ADC, it can accurately capture the subtle transient changes of microsecond-level signals while maintaining an RMS background noise of less than 1.5 mV. It becomes a cost-effective tool in the fields of industrial automation, consumer electronics, and educational research. Its 12.1-inch capacitive touchscreen and Windows CE platform provide an intuitive operation experience, supporting multi-task parallel processing and data analysis.
Product features
200 MHz
2 analog channels
Easy to view signals on a large 12.1-inch capacitive touch screen
With the unique area touch trigger function, signals can be isolated within seconds
With 4 Mpts of memory and segmented storage standard, more data can be captured
View more signal details at an update rate of 1,000,000 wfms/s
Expand measurement functions through a fully upgradeable design: increase bandwidth, digital channels, dual-channel 20 MHz arbitrary waveform generator, three-digit digital voltmeter, serial triggering, as well as analysis and mask testing, etc. at any time.
