Product Description:
The DSO9404A features a 4GHz bandwidth, 4 analog channels, a sampling rate up to 20GSa/s, and each channel has a standard memory of 20Mpts, which can be upgraded to 1Gpts. It is equipped with a 15-inch XGA display, has a compact body, a depth of only 23 centimeters, and weighs approximately 11.8 kilograms. This oscilloscope integrates the functions of an oscilloscope, a logic analyzer, and a protocol analyzer, and is widely used in scenarios such as fault detection of electronic circuits or components, production testing, and design.
Product features:
High bandwidth and high sampling rate: The 4GHz bandwidth can meet the measurement requirements of various high-frequency signals and can be used in fields such as communication and semiconductors. The 20GSa/s sampling rate can accurately capture the details of high-speed signals and ensure the true reproduction of signal waveforms, which is helpful for accurate analysis of signal characteristics.
Large storage depth and multiple channels: The standard storage depth of each channel is 20Mpts, which can be upgraded to 1Gpts, allowing for long-term signal recording and facilitating the capture of occasional transient signals. The 4 analog channels can simultaneously measure multiple signals, making it convenient for comparative analysis of signals. When paired with the MSO model, an additional 16 digital channels can be added to meet more complex measurement requirements.
