产品型号：安捷伦 DSO-X93204A

促销价 电议

产品详情

求购  /通用仪器/示波器/示波器

求购泰克 MDO3104 混合域示波器

浏览次数：60

紧急求购，资金齐备，坐等发货

产品参数

选件 保修时间 状态 是否计量
MDO3MSO 不保修 完好 否
成色 发货周期 所在地 数量
8成新 7天 深圳市 1
预算价格： 电议

邮件咨询

加入收藏

加入购物车
更新日期：2021-05-27
联系电话：0755-86016691

*产品描述

产品概述：

尽管MDO3000系列混合域示波器中包含其它内置仪器, 它的核心仍是一台示波器. 产品用于多样. MDO3104包含节省时间的使用工具, 帮助用户比以往更快地发现, 捕捉, 搜寻并分析设计中出现的问题. 尽管未来发展不可知, 用户可使用示波器随时做好准备. MDO3104是一个可完全升级的产品, 用户可根据测试发展需求为其添加仪器, 升级带宽. 它适合目前需求, 并可为未来做好准备. 它包含一个内置频谱分析仪, 装有独立射频采集系统用于大多数精确射频测量, 用户可将此仪器用作示波器和频谱分析仪, 同时不影响其性能.
  • 专用前面板控制可轻松放大并导航10 Mpoint记录
  • 250,000每秒的波形采集速率
  • 内置频谱和协议分析仪
  • 内置4数位电压表, 交流+直流RMS, 交流RMS, 和直流测量
  • 内置逻辑分析仪, 16数位通道
  • 集成的升级任意波形/函数发生器
  • 串行和并行总线触发和分析
  • FastAcq™高速波形捕捉速率可快速发现异常信号.
  • Wave Inspector®控制器提供方便的导航和自动搜寻波形数据
  • 33种自动测量和波形直方图, 用于简单的波形分析
  • 外形小巧, 重量轻 -- 5.8英寸 (147 mm)厚, 9.2 lb. (4.2 kg)
  • 前端和后端USB主端口可轻松传送屏幕快照, 设置和波形数据.
  • 仪器上的视频端口可输出显示至外部监示器或程序.
  • 通过仪器后部的标准10/100以太网端口可轻松接入网络.

应用

工业自动化控制, 无线, 仪器仪表, 电子设计, 电源管理, IoT (物联网), 嵌入式设计与开发, 工业, 研究开发, 测试与测量

更多>>

其他要求

Product Features:

  • TekVPI probe interface directly supports active, differential, and current probes for automatic scaling and units
  • 9 in. (229 mm) WVGA wide screen color display
  • Small footprint and lightweight – Only 5.8 in. (147 mm) deep and 9.2 lb. (4.2 kg)
  • FastAcq high-speed waveform capture rate finds elusive signal anomalies quickly
  • Wave Inspector Controls provide easy navigation and automated search of waveform data
  • 33 automated measurements and waveform histograms for simplified waveform analysis

Oscilloscope

  • 4 analog channel
  • 1 GHz bandwidth
  • Bandwidth is upgradable (up to 1 GHz)
  • Up to 5 GS/s sample rate
  • 10 M record length on all channels
  • >280,000 wfm/s maximum waveform capture rate
  • Standard passive voltage probes with 3.9 pF capacitive loading and 1 GHz, 500 MHz, or 250 MHz analog bandwidth

Spectrum Analyzer

  • Frequency Range:
    • Standard: 9 kHz - oscilloscope bandwidth
    • Optional: 9 kHz - 3 GHz
  • Ultra-wide capture bandwidth up to 3 GHz

Arbitrary Function Generator (Optional)

  • 13 predefined waveform types
  • 50 MHz waveform generation
  • 128 k arbitrary generator record length
  • 250 MS/s arbitrary generator sample rate

Protocol Analyzer (Optional)

  • Serial bus support for I2C, SPI, RS-232/422/485/UART, USB 2.0,CAN, LIN, FlexRay, MIL-STD-1553, and Audio standards

Digital Voltmeter (Free with product registration)

  • 4-digit AC RMS, DC, and AC+DC RMS voltage measurements
  • 5-digit frequency measurements

Spectral Analysis

  • Dedicated front-panel controls for commonly performed tasks
  • Automated peak markers identify frequency and amplitude of spectrum peaks
  • Manual markers enable non-peak measurements
  • Trace types include: Normal, Average, Max Hold, and Min Hold
  • Spectrogram display enables easy observation and insight into slowly changing RF phenomena
  • Automated measurements include: Channel Power, Adjacent Channel Power Ratio (ACPR), and Occupied Bandwidth (OBW)

Arbitrary Function Generation

  • Generate predefined signals to quickly simulate missing devices in designs
  • Capture signals on analog or digital inputs, transfer to the arbitrary edit memory, and replicate out from the AFG
  • Add noise to any signal to easily perform margin testing

Mixed signal design and analysis

  • Automated triggering, decode, and search on parallel buses
  • Multichannel setup and hold triggering
  • MagniVu high-speed acquisition provides 121.2 ps fine timing resolution on digital channels

Protocol Analysis

  • Trigger, decode and automatically search on packet-level content on most common embedded design serial bus standards
  • Export protocol decode tables for use in documenting results

Digital Voltmeter and Frequency Counter

  • Quickly validate voltage or frequency measurements at a glance
  • Graphical readout provides information on stability of the measurement

Fully upgradable

  • Add functionality, increase bandwidth or spectrum analyzer frequency range over time as your needs change or budget allows

Optional application support

  • Power analysis
  • Limit and mask testing

The Tektronix MDO3104 Mixed Domain Oscilloscope is the ultimate 6-in-1 integrated oscilloscope that includes an integrated spectrum analyzer, arbitrary function generator, logic analyzer, protocol analyzer, and digital voltmeter/counter. The Tektronix MDO3104 is completely customized and fully upgradable; Add the instruments and performance you need now - or later.
