Product Description:
The N6700C is a 400W, 1U high, 4-slot modular power supply system chassis. It can accommodate 1 to 4 N6700 series DC power modules in any combination, with a maximum total output power of 400W (under 100 - 240VAC input conditions). The AC input rating is 100VAC - 240VAC, 50/60/400Hz, the input voltage range is 86VAC - 264VAC, and the typical power consumption is 1000VA. It is equipped with standard GPIB, LAN and USB interfaces, and complies with the LXI standard. It has a fast protection response capability, starting to shut down within 5µs when the input is prohibited, and starting to shut down within 10µs when the coupling output fails.
Product Features:
Modular Design: Featuring 4 slots, it allows for selection from over 30 types of DC power modules. It can flexibly combine into DC power systems with 1 to 4 channels based on different testing requirements and budget, suitable for various scenarios such as semiconductor testing, communication equipment testing, etc.
Small Size, High Power: With only 1U rack space, it can provide a total power of 400W. Highly integrated, it saves space and is highly suitable for applications with high space requirements such as Automatic Test Equipment (ATE).
