Description:
The Santec HSL-1 is a single-mode high-speed wavelength-scanning light source independently developed by Santec Corporation. It is based on the tunable vertical-cavity surface-emitting laser (VCSEL) technology and integrates MEMS (Micro-Electro-Mechanical Systems) technology. This light source features outstanding mass production capabilities, high reliability, long lifespan, and low power consumption, and is suitable for various high-precision optical applications, such as optical coherence tomography (OCT), spectroscopic analysis, FMCW LiDAR, and others.
Feature:
Santec's tunable VCSEL technology
Wavelength: 1060nm
Long coherence length
Single-mode laser, noise-free
Scanning speed adjustable, bandwidth adjustable
Suitable for mass production
Supports OEM/Customization
USB interface
Main purpose:
OFDR
FMCW Laser Radar FBG interrogator
Shape sensing Main Performance:
Central wavelength: 1060nm
Maximum output power: ≥ 60mW
Scanning range: ≥ 75nm
Scanning rate: 10 - 400kHz (optional)
Coherence value: > 100 (theoretical value)
