浏览次数：103
| 选件 | 是否计量 | 发货周期 | 保修时间 | 成色 |
|---|---|---|---|---|
| 否 | 5天 | 90天 | 8成新 | |
| 所在地 | 机身号 | 状态 | 资料下载 | |
| 深圳市 | 完好 |
The YOKOGAWA WT1803R is a high-performance power analyzer with 3 input channels, belonging to the WT1800 series. It is equipped with USB, GPIB and Ethernet interfaces.
Feature:
High-precision measurement: The power accuracy can reach 0.05% of the reading plus 0.05% of the range, ensuring precise measurement of power parameters. At the same time, the low power factor error of apparent power is reduced to 0.1%, which is helpful for achieving high-precision measurement in low power factor scenarios.
Wide frequency bandwidth: The voltage and current frequency bandwidth is 5 MHz (-3dB, typical value), which can capture fast switching signals more accurately and meet the measurement requirements of high-frequency equipment such as frequency converters.
Wide measurement range: The direct input voltage range is 1.5V to 1000V (12 ranges), and the direct input current range is 10mA to 5A (9 ranges) or 1A to 50A (6 ranges), allowing for the measurement of tiny currents and expanding the measurement application range.
High-speed data acquisition: It can perform low-speed signal power measurement at 0.1Hz, with the data update rate reaching up to 50ms. In addition to normal measurement data, it can also simultaneously measure and save up to 500 high harmonic data.
Channel function: The WT1800 series can support up to 6 input channels. The WT1803R, as a 3-channel unit, can be combined with other units to meet more complex multi-channel measurement requirements and is suitable for power and efficiency testing scenarios of various electrical equipment.
