Product Description:
The 86120U advances the development of 850 nm optical transmitters operating at 2.5 Gb/s and higher. Built-in filters for transmitter compliance tests are available for 1250/2488 Mb/s data rates, and for 2488/3125 Mb/s data rates.The 86120U advances the development of 850 nm optical transmitters operating at 2.5 Gb/s and higher. Built-in filters for transmitter compliance tests are available for 1250/2488 Mb/s data rates, and for 2488/3125 Mb/s data rates.
Instrument Features:
15 GHz amplified optical channel for 62.5/125 fibers
Wavelength range: 750-860 nm
Characteristic rms noise: 14 uW (15 GHz BW)
Reference receiver capability (1.250/2.488 Gb/s or 2.488/3.125 Gb/s or 3.125/10.3125 Gb/s)
20 GHz electrical channel with 3.5 mm male input
Characteristic rms noise: 0.25 mV (12.4 GHz BW), 0.5 mV (20 GHz BW)
Maximum input signal: ± 2 Vdc
