Product Overview:
The modular TLA7000 logic analyzer family provides the speed and flexibility needed to capture logic detail in today's fastest designs. With the same probe, pinpoint elusive sources of error and get the visibility you need with a large, easy-to-read display, fast data throughput, and time-dependent view of analog and digital signals.
The TLA7012 Portable and TLA7016 desktop hosts are modular hosts that accept TLA logic analyzer and code generator modules. The TLA7012 and TLA7016 can be configured as master or extension hosts to provide a solution for large bus and high channel count requirements.
Product features:
68/102/136 channel logic analyzer with recording length up to 512 Mb
Burr and build time/hold time trigger and display can find and reveal elusive hardware issues
Transition storage extends signal analysis capture time for infrequently transitioned signals
Synchronous state, high-speed timing and analog analysis with the same probe enables precise location of elusive faults
Trace problems in real time across multiple modules, from symptoms to root causes, by viewing time-related data in a variety of display formats
Comprehensive PCI Express detection solutions, including intermediate buses, slot adapters, and welded connectors
Modular hosts provide flexibility and scalability
