Product Description:
The LDT-5910B is a microprocessor-based, precision thermoelectric temperature controllerdesigned for temperature control of laser diodes, detectors and other temperature sensitivedevices. The LDT-5910B can be used for laser diode testing, laser diode frequencystabilization, IR detector cooling, and to determine the characteristics of electronic devices.
The LDT-5910B combines high analog stability with the versatility of a microprocessor-based instrument. The internal microprocessor controls the operation of the LDT-5910B and performs the non-linear conversion of thermistor resistance to temperature based on three user defined constants. You can configure the LDT-5910B to operate with a wide variety of thermis tor temperature sensors and TE modules, as well as AD590 series and LM335 series temperature sensors. The model 1233 GPIB/IEEE-488 interface allows remote programming and completely automated control of the LDT-5910B.
Features:
-
Intuitive Front Panel Layout
-
Large and Easy-to-Read Green LED Display
-
Display Resolution of 0.1 Degree Centigrade
-
Output Current Limit Control to Safely Operate all TE Coolers
-
Configurable for a Variety of Thermal Sensors
-
Output will Supply 4 amps, 16 Watts
