Product Description:
DPO70804C oscilloscope provides excellent signal acquisition performance and analysis capabilities. Discover true signals with unfettered acquisition on all 4 channels and capture more signal detail with the industry's highest waveform capture capabilities. Automatically set up, capture, and analyze high-speed serial data signals with a toolset designed for faster design and conformance testing. The DPO70804C features the lowest noise in the industry and a sampling rate of up to 50GS/s across all four channels, ensuring that signal integrity checks and timing analysis can be done without worrying about noise and jitter in the oscilloscope distorting measurements. Single-transmission bandwidth of up to >20 GHZ on all four channels ensures that signals of interest are captured without worrying about under-sampling when using more than 1 or 2 channels. With a high signal-to-noise ratio and low internal background noise, accurate characteristic measurements can be performed. When debugging the DUT, the low background noise and maximum signal fidelity of the measuring instrument allow the detection of minimal anomalies that affect the performance of the DUT. For RF signals, the lower background noise translates into a higher dynamic range, making the DPO70804C more widely used.
Features:
Bandwidth 33GHz
Industry-leading 100GS/s sampling rate
Industry-leading signal fidelity, lowest noise and highest significant bits (ENOB)
All four channels feature the industry's highest waveform capture rates
16 logical channels with 80psec timing resolution (MSO70000 series only)
Analog/digital probe with multiple connection support options
