Product Description:
The Yokogawa WT1806 power analyzer offers a voltage and current frequency bandwidth of 5 MHZ and provides a power factor error (0.1%). The Yokogawa WT1806 unit offers a direct input voltage range from 1.5V to 1000V (12 ranges) and a direct input current range from 10Ma to 5a(9 range) or 1a to 50a(6 range). The measurement data can be displayed on a single screen of the wt1806, along with detailed Settings for each of the six inputs, such as voltage range, current range, synchronization source, wiring system and filter. You don't need to switch the display frequently to confirm the Settings. With the Yokogawa WT1806 power analyzer, the data update rate can be selected from 9 options, from the fastest data update rate of 50MS to the update rate of 20s for low speed measurements.
Product features:
X6-WT1806 External current sensor input
B5- Built-in printer
G5- Harmonic measurement or G6- synchronous double harmonic measurement
DT- Triangulation
FQ- Additional frequency measurement
V1 - RGB output
DAA output for DAO-20 channel
Opt 60: 5A/5A/5A/5A/5A/5A inputs
Target D=UL/CSA standard
He = English
ex6= External sensor input
G6= Double harmonic measurement
DT= trigonometry
V1=VGA output
OX= Auxiliary voltage sensor input
