Product Description:
Reduced test complexity, streamlined workflows, and an intuitive user interface make battery testing easier than ever.
As an ideal test tool, it enables the maintenance, fault diagnosis and performance testing of various batteries and battery packs for backup battery applications
Intuitive user interface, compact design and robust construction guarantee excellent performance, test results and reliability
A wide range of battery testing features include synchronous DC voltage and internal resistance acquisition, connected sheet resistance testing and synchronous temperature measurement using an interactive handle integrated with an infrared temperature measurement system
Specially designed to measure all types of backup batteries.
Product Features:
The BTL20 smart test probe set features a long and short probe and an extension bar, and incorporates a built-in LCD display and speakers that provide visual and audio feedback
BTL20ANG Smart Test Probe Set with Long and Short Corner Tip Probe Extender (No temperature sensor)
Carry a soft bag (large)
Battery voltage - During the internal resistance test, the Fluke battery analyzer can also measure the voltage of the battery under test.
Discharge Voltage-During discharge or load testing, the discharge mode collects the voltage of each cell multiple times at user-defined intervals. The user can calculate the time it takes for the battery voltage to drop to the termination voltage, and calculate the capacity loss of the battery from this time
Ripple voltage test - measures the residual AC component of the undesired rectifier voltage in DC charging circuits and inverters. Enables users to test the AC component in the DC circuit and identify the root cause of battery performance deterioration
Digital multimeter mode and Sequential Measurement Mode - Digital multimeter mode is used for quick testing or troubleshooting. In this mode, you can save and read readings in battery test order or time series. Sequential measurement mode is used for maintenance work of multiple power systems and battery packs. Before a task starts, the user can configure a profile for the task to manage data and generate reports
Thresholds and Warnings - Users can configure up to 10 sets of thresholds and receive a pass/warning/failure prompt after each measurement is completed
Intercell connector Resistance testing and data management - Measuring the connector resistance between a group of cells.
Autohold - When Autosave is enabled, a measurement reading is captured if it remains stable for 1 second. Then, the reading is reset when starting a new measurement
Automatic MEASUREMENT SAVING - WHEN AUTOMATIC MEASUREMENT saving is enabled, AN automatic measurement reading will be automatically saved to the internal memory after it is captured
Fluke Battery Management software - Easily import data from this product to PC. Measurement data and battery archive information are stored and archived by management software and can be used for comparison and trend analysis. Easily generate reports using all measurement data, battery profiles, and analysis information
Comprehensive recording - All measurements are automatically captured during the test and can be viewed on the instrument before being downloaded for analysis at any time
Optimized user interface - quick, guided setup ensures you're capturing the right data every time
Battery life - The 7.4V 3000 mAh lithium-ion battery can run continuously for more than 8 hours.
USB port - enables quick download of data to the accompanying data analysis and report management application.
Safety class - CAT III 600 V, maximum DC 1000 V, suitable for safety measurement of all battery power equipment.
