Product Description:
The 2611B System SourceMeter SMU instrument is an industry-leading current/voltage source and measurement solution built with Keithley's third-generation SMU technology. Available in single and dual channel models, the 2611B combines the functions of a precision power supply, true current source, 6½-digit digital multimeter, arbitrary waveform generator, pulse generator, and electronic load into one tightly integrated instrument.
The result is a powerful solution that dramatically increases productivity for applications ranging from benchtop I-V characterization to highly automated production testing. Built-in web browser-based software enables I-V testing from any computer anywhere in the world. Alternatively, use your Android smart device to perform plug-and-play I-V testing with fingertip control via the Keithley IVy app. For automated system applications, the 2611B Test Script Processor (TSP®) runs complete test programs from within the instrument for the industry's best throughput.
Product Features:
-
Tightly integrated 4-quadrant voltage/current source and measurement instrumentation delivers best-in-class performance with 6½-digit resolution
-
Built-in web browser-based software enables remote control from any browser, from any computer, from anywhere in the world
-
Compatibility with the Keithley IVy mobile app enables true plug-and-play I/V characterization and testing with any Android device
-
TSP (Test Script Processing) technology embeds complete test programs inside the instrument for optimal system-level throughput
-
TSP-Link extension technology for multi-channel parallel testing without host
-
Software Emulation of the Keithley 2400 SourceMeter SMU Instrument
Product Parameter:
-
Channel: 1
-
Power: 200 watts
-
Maximum current source/measurement range: 10A
-
Maximum voltage source/measurement range: 200V
-
Measurement Resolution (Current/Voltage): 100fA/100nV
