Product Description:
The 6240B is an SMU (Source Monitoring Unit) equipped with high speed response pulse generation/measurement and low resistance measurement for testing contact resistance of connectors, etc.
It has a voltage and current generation accuracy of 4½ bits and a measurement accuracy of 5½ bits, with a basic accuracy of ±0.02%. Scanning mode in addition to linear, fixed, random, two-slope linear scanning (switching step value in the middle of the scan), also has a minimum pulse width of 50μs pulse measurement function, so can be used for measurement can be widely used in research and development evaluation power supply and production line characteristics test system power supply.
In addition, low resistance testing of connectors and low resistance measurements of conductive materials can be performed according to JIS. In addition, contact resistance can be measured with high accuracy by eliminating thermoelectric EMFs generated on metal contact surfaces such as wire harnesses.
Product Features:
Power supply/measuring range Voltage:
0 to ±15 V, current: 0 to ±4 A (DC: 1 A)
Basic accuracy: ±0.02% source and measurement
5½ bits (±319999), resolution 1 μV/100 pA measurement
Can output/absorb ±4 A current for up to 20 ms
Pulse measurement with a minimum pulse width of 50 μs and resolution of 1 μs
Reversible bipolar output
Achieve low resistance and contact resistance measurements for eliminating thermoelectric EMF, such as conductive materials, connectors, wiring harnesses, etc.
