| 选件 | 是否计量 | 发货周期 | 保修时间 | 成色 |
|---|---|---|---|---|
| 否 | 1-4周 | 12- | 8成新 | |
| 所在地 | 机身号 | 状态 | 资料下载 | |
| 深圳市 | 完好 |
URV55是Rohde＆Schwarz的仪表。仪表是一种用于测试和测量交流（AC）或直流（DC）电压，电阻，RF，电流等的仪器。
附加功能：
R＆S URV55毫伏表适用于高达3 GHz的电压测量以及高达40 GHz的功率和电平测量。由于带有带有校准数据存储器和温度传感器的探头，这些探头可以由用户进行不必要的调整，因此URV55可以提供高精度的测量，而不会出现操作员错误。
URV5-Z系列测量头的全面范围包括高阻抗电压探头以及用于同轴线上电压测量的插入单元。此外，URV55可以使用所有NRV-Z系列的热功率和二极管传感器。URV55测量的电压范围为200μV至1000 V，覆盖的频率范围为DC至3 GHz。功率测量最高可达40 GHz。
The URV55 is a meter from Rohde & Schwarz. A meter is an instrument used to test and measure alternating current (AC) or direct current (DC) voltage, resistance, RF, electric current, and much more.
Additional Features:
The R&S URV55 Millivoltmeter is suitable for voltage measurements up to 3 GHz as well as for power and level measurements up to 40 GHz. Thanks to probes with calibration data memory and temperature sensors, which make adjustments by the user superfluous, the URV55 provides high-precision measurements that are free of operator error.
The comprehensive range of measuring heads of the URV5-Z series includes high-impedance voltage probes as well as insertion units for voltage measurements on coaxial lines. In addition, all thermal power and diode sensors of the NRV-Z series can be used with the URV55. The URV55 measures voltages in the range from 200 μ V to 1000 V and covers the frequency range from DC to 3 GHz. Power measurements are possible up to 40 GHz.
