浏览次数：752
| 选件 | 是否计量 | 发货周期 | 保修时间 | 成色 |
|---|---|---|---|---|
| 否 | 1-4周 | 12- | 8成新 | |
| 所在地 | 机身号 | 状态 | 资料下载 | |
| 深圳市 | 完好 |
LMG95单相精密功率计是ZES ZIMMER精密功率测量装置经过验证的LMG系列的杰出产品。高精度，连续无间隙的信号测量和处理，符合人体工程学的操作和结果显示，与高数据速率的接口，可用于高效的系统应用-这些是LMG95的特色。
可以轻松进行开发，质量保证和制造中所需的组件和设备的高精度功率测量，而与电流和电压是正弦波还是失真，负载是否为线性或电路是否正常无关以斩波，脉冲或其他调制模式。在被测信号的周期性上扩展同步的可能性总是产生独特而稳定的测量显示和结果。
具有直接测量范围高达600V（1600Vpeak）和20A（用于涌入电流的测量的960Apeak）的隔离测量输入，以及使用分流器或其他传感器进行电流测量的输入，可以精确且无畸变地测量输入的测量信号。
它的基本精度为0.025％，是同类产品中最精密的仪器，因此可作为电能表，功率计，功率测量变压器和电流和电压电表的参考设备。
基本单元中已经提供了完全符合EN61000-3-2 / -12标准的谐波分析。选配符合EN61000-4-15的闪烁计（用于测量闪烁（电压变化））和EN61000-3-3 / -11。这两个功能还极大地扩展了LMG95在研发实验室中的可能应用。如果有合适的稳定电压源，则可以根据EN61000-3-2 / -3 / -11 / -12进行CE符合性测试。
LMG95在CE测试系统中用作分析仪，以测试电气设备的谐波和闪烁及其对电源的影响。ZES ZIMMER测试系统CE-Test61k通常配备用于三相应用的精密功率计LMG500或用于单相应用的LMG95。组件也可以单独订购和使用，轻松集成客户拥有的电源。
LMG系列的所有ZES ZIMMER功率计，PCT系列的电流传感器和HST系列的电压传感器在出厂前均经过仔细测试，调整和校准，并受到严格的质量控制。
ZES ZIMMER保证自首次交付以来的24个月内，这些产品不存在材料或工艺上的缺陷。
The LMG95 single-phase precision power meter is an outstanding product in the proven LMG series of ZES ZIMMER precision power measuring devices. Highly accurate continuously gapless signal measurement and processing, ergonomic operation and presentation of the results, interfaces with high data rates for effi cient system applications – these are the performance features which distinguish the LMG95.
The high precision power measurements on components and devices that are required in development, quality assurance and manufacturing can be performed with ease, independent of whether the current and voltage are sinusoidal or distorted, whether the load is linear or not, or whether the circuit works in a chopped, pulsed or another modulation mode. The extended possibilities of synchronization on the periodicity of the measured signal always produce distinct and stable measurement displays and results.
Isolated measurement inputs with direct measurement ranges up to 600V (1600Vpeak) and 20A (960Apeak for the measurement of inrush currents) and the input for current measurements using a shunt or other transducer measure the incoming measurement signals exactly and without any aberrations.
With a basic accuracy of 0.025% is this the most precise instrument in its class and therefore it is used as a reference device for energy meters, power meters, power measurement transformers and trms meters for current and voltage.
The harmonic analysis in full compliance with the EN61000-3-2/-12 standard is already available in the basic unit. The fl icker meter in compliance with EN61000-4-15 for the measurement of fl icker ( voltage variations) and with EN61000-3-3/-11 is available as an option. These two functions also considerably extend the possible applications of the LMG95 in R&D laboratories. If suitable stable voltage sources are available, tests for CE compliance can be performed in accordance with EN61000-3-2/-3/-11/-12.
The LMG95 is used as an analyzer in CE test systems to test electrical devices on harmonics and fl icker and their effect on mains. The ZES ZIMMER test system CE-Test61k is usually equipped with a precision power meter LMG500 for 3-phase application or with a LMG95 for singlephase applications. Components can also be ordered and used separately, easy integration of customer owned power sources.
All ZES ZIMMER power meters of the LMG series, the current sensors of PCT series and the voltage sensors of the HST series are carefully tested, adjusted and calibrated prior to shipment and are subject to strict quality controls.
ZES ZIMMER guarantees for a period of 24 months from first delivery that these products are free from defects in material or workmanship.
