| 选件 | 是否计量 | 发货周期 | 保修时间 | 成色 |
|---|---|---|---|---|
| 否 | 1-4周 | 12月 | 8成新 | |
| 所在地 | 机身号 | 状态 | 资料下载 | |
| 深圳市 | 完好 |
产品描述：
AI9322A高稳定度双波长激光光源是带微处理器的智能化高稳定度光源，具有的性能价格比。不论是进行光纤、光缆及光无源器件插入或传输损耗测试，还是用于建立光损耗、衰减等计量标准，它均可提供所需要的高稳定度光输出，可以对被测器件进行长期高精度的测量。
AI9322A双波长激光光源采用了高性能的自动光功率控制(APC)技术和自动温度控制(ATC)技术，从而保证了输出光功率有极高的稳定性，达到了±0.003dB/15min的短期稳定度和±0.03dB/12h的长期稳定度(选件001),具备当前国际先进水平。
AI9322A双波长激光光源为用户提供了内外调制功能，可为用户提供斩波光信号输出、或作为E／O变换器使用。光源还具有GP-IB接口功能,可以方便地组成自动测试系统,适应自动化测量的要求,是国内开发出的种带GP-IB接口的高稳定度双波长激光光源。
|
主要特征： |
|
·微处理器控制的智能化仪器 |
|
性能指标： |
|
光发射器件 FP-LD/DFB-LD |
Product Description:
AI9322A high-stability dual-wavelength laser light source is an intelligent high-stability light source with a microprocessor, which has a price-performance ratio. Whether it is used to test the insertion or transmission loss of optical fibers, cables, and optical passive devices, or to establish measurement standards such as optical loss and attenuation, it can provide the required high-stability optical output, which can perform long-term high performance on the device under test Measurement of accuracy.
AI9322A dual-wavelength laser light source uses high-performance automatic optical power control (APC) technology and automatic temperature control (ATC) technology, thereby ensuring extremely high stability of the output optical power, reaching a short-term stability of ± 0.003dB / 15min Degree and ± 0.03dB / 12h long-term stability (option 001), with the current international advanced level.
AI9322A dual-wavelength laser light source provides users with internal and external modulation functions, which can provide users with chopper optical signal output or use as an E / O converter. The light source also has a GP-IB interface function, which can easily form an automatic test system to meet the requirements of automated measurement. It is a kind of high-stability dual-wavelength laser light source with GP-IB interface developed in China.
