浏览次数：3033
| 选件 | 是否计量 | 发货周期 | 保修时间 | 成色 |
|---|---|---|---|---|
| 否 | 4-8周 | 12- | 全新 | |
| 所在地 | 机身号 | 状态 | 资料下载 | |
| 深圳市 | 完好 |
PLS-100是一种具有明确极化的光源。它具有稳定的高输出功率，同时保持较高的功率偏振消光比（PER）为45dB（典型值）。结合PLS-100和PEM-330（偏振消光比测量仪）提供优化的PER测量系统两者中的偏振保持（PM）光纤器件研发和生产环境。
应用
规格
|
Parameter
|
Unit
|
Specification
|
Notes
|
| Wavelength Range |
nm
|
1310±20 or 1550±20
|
|
| Polarization Extinction Ratio (PER) |
dB
|
40
|
45dB typically
|
| PER Stability @1hour *1 |
dB
|
±0.5
|
±0.1 typically
|
| Output Power |
dBm
|
0
|
+3dBm typically
|
| Power Stability @1hour *1 |
dB
|
<±0.1
|
±0.05 typically
|
| Power Variation by changing angle |
dB
|
±0.2
|
|
| Linewidth (FWHM) *2 |
nm
|
>20
|
|
| Optical Connector |
–
|
FC or SC
|
|
| Connector Polish |
–
|
SPC
|
|
| Polarized Axis Adjustment |
deg
|
2
|
Fine adjustment
|
|
deg
|
180
|
Coarse adjustment
|
|
| Operating Temperature |
℃
|
15 to 35
|
|
| Size (W) x (D) x (H) |
mm
|
210x350x135
|
except for the protruding portion
|
| Weight |
kg
|
3.5
|
|
| Supply Voltage |
V
|
AC100-240 ±10%
|
|
| Frequency |
Hz
|
50/60
|
|
All measurements are taken after 60 min warm up and at stable room temperature.
*1: For period of 1 hour. Within ± 0.5 ºC.
*2: Measured at Full Width Half Maximum
summary：
PLS-100 is a light source with well-defined polarization. It has a stable high output power while maintaining a high power polarization extinction ratio (PER) of 45dB (typical value). Combining PLS-100 and PEM-330 (polarization extinction ratio measuring instrument) provides an optimized PER measurement system in both polarization maintaining (PM) fiber optic device development and production environments.
performance：
performance：
