浏览次数：322
| 选件 | 是否计量 | 发货周期 | 保修时间 | 成色 |
|---|---|---|---|---|
| 否 | 0天 | - | 全新 | |
| 所在地 | 机身号 | 状态 | 资料下载 | |
| 深圳市 | 完好 |
|
Parameter
|
Unit
|
Specifications
|
Notes
|
| Sensor element |
–
|
InGaAs
|
|
| Wavelength range |
nm
|
1250 to 1650
|
|
| Specification wavelength range |
nm
|
1270 to 1630
|
|
| Dynamic power range |
dBm
|
-80 to +5
|
|
| Maximum safe power |
dBm
|
+16
|
|
| Total uncertainty |
%
|
±5
|
@>-60dBm
|
| Power resolution |
dB
|
0.01
|
|
| Linearity |
dB
|
±0.03
|
@>-60dBm
|
| Polarization dependent responsivity (typ.) *1, 2 |
dB
|
<0.025
|
@1525-1585nm
|
|
<0.03
|
@1270-1630nm
|
||
| Averaging time |
sec
|
50μ to 10
|
|
| Port number per module |
–
|
4 ports
|
|
| Data logging capability |
–
|
1,000,000 per port
|
|
| Connector type |
–
|
FC or SC
|
|
| Operating temperature |
deg
|
10 to 40
|
|
| Operating humidity |
%
|
<80
|
non condensing
|
*1: Temperature: 20-30 deg C,
*2: SMF, Straight connector
