产品描述：
5500A是Fluke的多功能校准器。工程师可能需要一个声级校准器，射频校准器，功率计校准器，电压电流校准器，或其他类型的电子测试设备校准。电子校准是维护设备进行一般监测和测试的必要条件。校准器使您能够在现场用自己的设备解决问题。
Fluke 5500A是一种革命性的产品，解决了您的电气校准工作负载的广泛截面。它提供直接电压和电流，多波形和谐波的交流电压和电流，两个同时的电压输出或电压和电流，并通过相位控制，电阻，电容，热电偶和rtd模拟功率。5500A的示波器校准选项提供水平正弦波，快速边缘，时间标记和振幅信号，用于校准高达600 MHz的示波器。
特点：
这些校准器适用于各种中等精度的电气测量设备，包括:
手持式和台式万用表
示波器
瓦特计
模拟,伏特/欧姆/ amp /瓦特仪器
电子温度计
数据记录器
带图表记录器
电力谐波分析仪
过程校准器
电流钳及相关仪器
Product Description:
The 5500A is a Multifunction Calibrator from Fluke. Engineers may need a sound level calibrator, radio frequency calibrator, power-meter calibrator, voltage-current calibrator, or another type for electronic test equipment calibration. Electronic calibrations are necessary for maintaining your equipment for general monitoring and testing purposes. Calibrators enable you to solve problems with your equipment on your own, on site.
The Fluke 5500A is a revolutionary product that addresses a wide cross-section of your electrical calibration work load. It sources direct voltage and current, alternating voltage and current with multiple waveforms and harmonics, two simultaneous voltage outputs or voltage and current, and simulates power with phase control, resistance, capacitance, thermocouples, and RTDs. The Oscilloscope Calibration options of the 5500A provide level sine wave, fast edge, time mark, and amplitude signals for calibration of oscilloscopes up to 600 MHz.
Features:
DC Voltage Range: 0 to ±1020V
DC Current Range: 0 to ±11A
Resistance Range: 0 to 329.999 MΩ
AC Voltage Range: 1 mV to 1020V
AC Current Range: 29 mA to 11A
Capacitance Range: 0.33 nF to 1.1 mF
DC Power Range: 109 mW to 11 kW
AC Power Range: 109 mW to 11 kW
Phase Power Range: 0 to ± 179.99°
Frequency Range: 0.01 Hz to 2.0 MHz
These calibrators were designed to cover a very wide range of medium accuracy electrical measurement devices including:
Handheld and bench multimeters
Oscilloscopes
Wattmeters
Analog,volt/ohm/amp/watt instruments
Electronic thermometers
Data loggers
Strip chart recorders
Power harmonics analyzers
Process calibrators
Current clamps and related instruments
