Product Introduction:
The MDO3052 is a 500 MHz, 2-channel mixed-domain oscilloscope from Tektronix. Measure the voltage or current signal in an electronic circuit or component as a function of time to show amplitude, frequency, rise time, etc. Applications include troubleshooting, production testing, and design.
Additional Features:
-
The FastAcq™ high-speed waveform capture rate allows you to quickly detect elusive signal anomalies
-
The Wave Inspector® control provides easy navigation and automatic search of waveform data
-
Automated measurement and waveform histograms simplify waveform analysis
-
The TekVPI® probe interface directly supports automatic scaling and unscaling of active, differential, and current probes
-
9. (229 mm)WVGA widescreen color display
-
Small footprint and light weight, only 5.8 inches. (147 mm) deep, 9.2 lb (4.2 kg)
-
All parts and labor of the MDO3000 instrument are guaranteed for three years
-
One year warranty, including all parts and artificial probes
-
The oscilloscope
-
500 MHz bandwidth:
-
The bandwidth can be upgraded to 1ghz
-
2 Analog channel
-
Sampling rate :2.5 GS/s
-
The recording length of all channels is 10 meters
-
>280,000 wfm/s maximum waveform capture rate
-
Standard passive voltage probe with 3.9 pF capacitive load and 1 GHz, 500 MHz or 250 MHz analog bandwidth
