Product Description:
The high-performance AQ3545 Optical Channel Selector comes with one or two selectable common I/O optical connectors (COM1 and COM2 ports), and 16 selectable I/O optical connectors (CH1 to CH16). Input is possible through either COM1 or COM2 ports, and any of CH1 to CH16. This means it is possible to connect light sources to COM1 and COM2, and output the either to ant of the connected transmission paths. Likewise, multiple light sources can be connected to channels 1 through 16, and the output switched to either COM1 or COM2. With excellent selection repeatability, low insertion loss, high return loss and low dependence on polarization, it is easier than ever to construct automatic measurement systems for development, manufacturing and inspection tasks in optical transmission systems and devices.
Features：
-
Selectable channles： 1x16
-
Wavelength range： 850/1300 nm
-
Insertion loss： 3.0 dB or less
-
Selection repeatability： 0.02 dB P-P or less
-
Adjacent channel switching time： 500 ms or less
-
Polarization dependency loss： 0.05 dB P-P
-
Crosstalk：-80 dB or less
-
Tyr. Selector life： 10 million cycles
-
Applicable optical fiber ：GI 150/125 µm
-
I/O Connectors： FC-PC
-
Power requirement： AC 100 to 120 V, 200 to 240 V, 50/60 Hz, approx. 50 V A
