Product Description:
Site Master Handheld Cable and Antenna Analyzer Model S331D covers the spectrum from 25 MHz to 4000 MHz. Suitable for field technicians of any experience level to use VHF, broadcast, paging, cellular, PCS/GSM, 3G, ISM, WLAN and WLL applications.
Measurement functions include accurate return loss/SWR, cable loss, and optional T1/E1 and power meter measurements. Frequency domain reflectometry (FDR) provides distance to fault (DTF) analysis to accurately locate faults.
Features:
-
Hand-held operation, battery-powered design
-
It weighs less than 5 lbs. (Including battery)
-
Built-in global signal standards and channels
-
TFT color display, visible color display in daylight
-
Excellent anti-radio frequency interference ability
-
517 data points, able to measure problems on a longer range
-
Multiple power measurement solutions
-
Built-in editable signal standard and cable standard list
-
Multilingual user interface: English, French, Chinese, Japanese, Spanish and German
-
Intuitive and easy-to-use screen test equipment
-
Able to store 10 to 30 measurement test equipment (10 VNA, 5 T1, 5 E1, power meter, 5 high-precision power meter)
-
Store up to 300 measurement traces
-
Use alphanumeric labels to number stored measurements
-
Automatically add storage date and time stamp
-
Both rechargeable and field-replaceable batteries
-
The distance measurement unit adopts two units of feet and meters
-
Information screen provides cable attenuation and propagation velocity values
-
6 markers, boundary lines, and segment boundary lines
-
RS232 interface
