Product Overview
TEKTRONIX DPO5104 Oscilloscope
The Tektronix DPO5104 Digital Phosphor Oscilloscope provides feature-packed tools that simplify and speed debugging of complex and mixed signal designs as well as help to capture intermittent events that other oscilloscopes often miss. With this single powerful instrument up to 20 analog and digital signals can be analyzed, its high bandwidth ensures observation of rapidly-changing signal details, and deep record lengh allows the capturing of long windows of signal activity.
Features and Specifications of the Tektronix DPO5104 Oscilloscope include:
-
Features:
-
Key Features:
-
Wave Inspector® Controls: easy navigation and automated search of waveform data
-
MyScope® custom control windows and right mouse click menu
-
Simplified waveform analysis with:
-
53 automated measurements
-
Waveform histograms
-
FFT analysis
-
>250,000 wfms/s waveform capture rate with FastAcq™
-
TekVPI® probe interface: supports active, differential, and current probes
-
User-selectable bandwidth limit filters for better low-frequency measurement accuracy
-
Suite of advanced triggers, with optional visual trigger
-
Bright XGA display:
-
10.4 in. (264 mm)
-
Touch Screen
-
Small footprint and lightweight:
-
8.12 in. (206 mm) deep
-
less than 15 lb. (6.7 kg)
-
Standard removable hard disk drive
-
Connectivity:
-
USB 2.0 host ports:
-
2 on the front panel
-
4 on the rear panel:
-
quick and easy data storage
-
printing
-
connecting USB peripherals
-
USB device port on the rear panel:
-
easy connection to a PC or GPIB control with an adapter
-
Integrated 10/100/1000BASE-T Ethernet port:
-
network connection
-
video out port to export the oscilloscope display to a monitor or projector
-
Microsoft® Windows 7 64-bit operating system
-
LAN and USB connectivity
-
LXI Class C compliant
-
Optional Serial Triggering and Analysis:
-
Automated serial triggering, decode, and search options for I2C, SPI, RS-232/422/485/UART, and USB
-
Automated serial decode and vehicle network monitoring of CAN and LIN
-
Optional Technology Specific Analysis:
-
Software solutions provide built-in domain expertise for Ethernet and USB 2.0 compliance testing, jitter, timing, eye diagrams, power, DDR memory bus analysis, and wideband RF
-
Limit and mask testing provide quick insight into signal characteristics
-
Specifications:
-
Vertical System Analog Channels:
-
Input Channels: 4
-
Analog Bandwidth (-3 dB): 1 GHz
-
Rise Time (calculated): 350 ps
-
DC Gain Accuracy: ±1.5%, derated at 0.10%/°C above 30 °C
-
Effective number of bits (typical): 6 bits (10 divisionp-p sine wave input at instrument bandwidth, 100 mV/div, 50 Ω Input Impedance, maximum sample rate, 1k point record length)
-
Random Noise (RMS, sample mode, full BW):
-
1 MΩ: ≤(150 μV + 8.0% of V/div setting)
-
50 Ω: ≤(75 μV + 6.0% of V/div setting)
-
Input Coupling: AC, DC
-
Input Impedance:
-
Input Sensitivity:
-
1 MΩ: 1 mV/div to 10 V/div
-
50 Ω: 1 mV/div to 1 V/div
-
Vertical Resolution: 8 bits (>11 bits with Hi Res)
-
Maximum Input Voltage, 1MΩ:
-
300 VRMS CAT II, with peaks = ±425 V
-
For
-
For =100 mV/div derate at 20 dB/decade above 3 MHz to 30 VRMS at 30 MHz, 10 dB/decade above 30 MHz
-
Max Input Voltage,50 Ω: 5 VRMS, with peaks ≤ ±20 V
-
Position Range: ±5 divisions
-
Delay between any 2 channels (typical): ≤100 ps (50 Ω, DC coupling and equal V/div at or above 10 mV/div)
-
Channel-to-Channel Isolation (any 2 channels at equal vertical scale settings) (typical):
-
≥100:1 at ≤100 MHz
-
≥30:1 at >100 MHz up to the rated BW
-
Horizontal System Analog Channels:
-
Max Sample Rate: 5 GS/s
-
Max Equivalent Time Sampling Rate: 400 GS/s
-
Max Record Length with Standard Configuration: 12.5M
-
Max Record Length with Opt 2RL: 25M
-
Max Record Length with Opt 5RL: 50M
-
Max Record Length with Opt 10RL: 125M
-
Maximum Duration at Highest Real-Time Sample Rate: 25 ms
-
Time Base Range: 12.5 ps/div to 1000 s/div
-
Time Resolution (in ET/IT mode): 2.5 ps/div
-
Time Base Delay Time Range: –10 divisions to 1000 s
-
Channel-to-Channel Deskew Range: ±75 ns
-
Time Base Accuracy: ±5 ppm over any ≥1 ms interval
