Keysight 33500B Series — Waveform Generator, 20 MHz, 2-Channel with Arb:
33500B Series waveform generators with exclusive Trueform signal generation technology offer more capability, fidelity and flexibility than traditional DDS generators. Use them to accelerate your development process from start to finish. Over the past two decades, direct digital synthesis (DDS) has been the waveform generation technology of choice in function generators and economical arbitrary waveform generators. DDS enables waveform generators with great frequency resolution, convenient custom waveforms, and a low price. As with any technology, DDS has intrinsic downsides and limitations as well. Engineers with exacting requirements have had to either work around the compromised performance or spend up to 10 times more for a high-end, point-by-point waveform generator.
This Instrument's Features:
-
160 MSa/s sampling rate for higher time resolution arbitrary waveforms
-
16-bit resolution with 1 mVpp to 10 Vpp amplitude for greater amplitude accuracy
-
1 MSa/channel standard waveform memory, optional 16 MSa/channel for your longest waveforms
-
USB, LAN (LXI-C), GPIB standard for quick and easy connectivity to PC or network
-
BenchVue Enabled. Control your waveform generator from your PC easily
Exclusive Trueform Technology:
-
Unmatched capabilities for generating a full range of signals for your most demanding measurements
-
Sine waves with 5x lower harmonic distortion for more pure signals
-
Pulses up to 20 MHz with 10x less jitter for more precise timing
-
Optional point-by-point arbitrary waveform capability with sequencing for more accurate representation of user-defined signals
Waveform creation and editing:
-
Get advanced signal creation/editing capability without tedious programming with
-
33503A BenchLink Waveform Builder Pro and Basic Software
-
Create a waveform from the front panel using the built-in editor
-
Capture a waveform from an oscilloscope and download it to the generator
-
Create a waveform in MATLAB, Microsoft® Excel, etc. and download it to the generator
Series Features:
-
Full-bandwidth pulse to 20 or 30 MHz
-
Set leading and trailing edge times independently
-
Dual channel coupling, frequency and amplitude, equal and inverted
-
Set start phase for each channel, set phase shift between channels
-
Sum two signals together, frequency and amplitude independent
-
2-tone, square-sine, noise on pulse
-
Create up to 1 million samples standard, 16 million optional
-
Connect arbs together, create up to 512 sequences
-
Lowest voltage range at 1 mVpp, a 10x improvement
-
Set high and low voltage limits to prevent overload on DUT
-
Provides standard PRBS patterns, PN7 ... PN23
-
Select PN type, set bit rate, set edge time
