The Keysight MSOX4024G is a high-performance mixed-signal oscilloscope. The following is an overview of its products:
Excellent Signal Observation Ability: With a bandwidth of 200MHz, it can accurately measure and analyze signals of various frequencies. It has 4 analog channels and 16 digital channels, enabling the capture and analysis of 20 signals simultaneously, making it suitable for debugging complex digital and analog mixed-signal systems.
High Sampling Rate and Deep Memory: The maximum sampling rate for half channels is 5GSa/s, and for all channels, it is 2.5GSa/s, which can precisely capture the details of rapidly changing signals. With a maximum memory depth of 4Mpts, it can store a large amount of data, facilitating long-term signal monitoring and in-depth analysis.
High-quality Display and Operation Interface: Equipped with a 12.1-inch high-definition capacitive touchscreen and an intuitive user interface, it is convenient to operate. It has the InfiniiScan Zone touch trigger function, which can isolate signals within a few seconds, improving the efficiency of signal analysis. In addition, with an update rate of 1 million waveforms per second, users can view more signal details.
Rich Measurement Functions: It comes standard with a variety of advanced functions, including a dual arbitrary waveform generator, template testing, frequency response analysis, histograms, and hardware-based serial decoding functions, etc., which can meet various measurement requirements. Its measurement capabilities can also be expanded through upgrades, such as adding bandwidth, a 3-digit DVM, serial triggering, and analysis, etc.
