Keysight N4691A MW 电子校准（ECal）模块可以快速、轻松、准确地校准矢量网络分析仪。RF ECal 系统现在可以通过两种方法之一轻松控制，具体取决于网络分析仪。Keysight PNA 和 ENA 系列网络分析仪通过 USB 接口直接控制模块。
ECal 是校准网络分析仪的理想解决方案。与机械校准套件相比，使用 ECal 执行完整的双端口校准所需的时间和连接数量不到一半。此外，电子和机械方法的校准精度相当。传统的机械校准需要大量的作员干预，这很容易出错。使用 ECal，作员只需将 ECal 模块连接到网络分析仪，其余部分由软件控制。
USB interface for direct control of PNA and ENA series network analyzers
Rapid calibration
Full dual-port calibration is achieved through a single connection
Reduce the wear of connectors
Accurate calibration traceable by NIST
Reliable solid-state switch
Direct and non-insertable device calibration
The Keysight N4691A MW Electronic Calibration (ECal) module can calibrate vector network analyzers quickly, easily and accurately. The RF ECal system can now be easily controlled by one of two methods, depending on the network analyzer. The Keysight PNA and ENA series network analyzers directly control the module via the USB interface.
ECal is an ideal solution for calibrating network analyzers. Compared with mechanical calibration kits, the time and number of connections required to perform a complete dual-port calibration using ECal are less than half. Furthermore, the calibration accuracy of electronic and mechanical methods is comparable. Traditional mechanical calibration requires a large amount of operator intervention, which is prone to errors. With ECal, the operator only needs to connect the ECal module to the network analyzer, and the rest is controlled by software.
USB interface for direct control of PNA and ENA series network analyzers
Rapid calibration
Full dual-port calibration is achieved through a single connection
Reduce the wear of connectors
Accurate calibration traceable by NIST
Reliable solid-state switch
Direct and non-insertable device calibration
Provide user characteristics
