Product Description:
The 86142B is a high-performance bench-top optical spectrum analyzer (OSA) launched by Tektronix. The 86142B is mainly used for analyzing optical signals within the wavelength range of 600nm to 1700nm. It is applicable in fields such as telecommunications, fiber optics, and photon research, and can be used for characterizing the properties of optical devices, optical networks, and optical systems.
Product Features:
High-precision measurement: The wavelength accuracy can reach ±10pm. The typical repeatability is ±0.002nm, and the absolute accuracy after factory calibration is ±0.5nm.
Wide wavelength range: It covers S, C and L wavelength bands, with a wavelength range of 600nm to 1700nm, meeting the requirements of various optical communication applications.
High dynamic range: With a resolution bandwidth of 0.1nm, the dynamic range can reach up to 70dB, suitable for detecting weak signals near strong signals.
Fast scanning: The scanning speed is fast, up to 56.3ms for scanning 40nm, and the cycle time within the 50nm range is less than 180ms, which can improve measurement efficiency.
Low polarization dependence: It has low polarization sensitivity, providing stable and accurate measurement results in different polarization states, suitable for testing WDM components and systems that are sensitive to polarization.
