Product Description
PHOENIX 1200 is a miniaturized external cavity tunable laser. It is equipped with a built-in low-noise high-linear sweep drive circuit and integrates a NIST traceable wavelength meter, enabling sub-pimetric wavelength measurement and control. The wavelength range covers 1515-1565nm C band, with a non-jump tuning range of 50nm. The output power is 8-10mW, the linewidth is 1.5MHz, the tuning rate is 1-1000nm/s. It supports external triggering and dual-channel optical power monitoring. It can be flexibly controlled through USB/BNC interface and the accompanying software. The module size is 23.5×12.0×4.5cm, using SM FC/APC interface, suitable for laboratory and integrated applications.
Core feature
Ultra-high wavelength accuracy and resolution: Built-in wavelength meter accuracy ±0.5pm, absolute wavelength accuracy ±1.5pm, set resolution 0.01pm, wavelength meter linearity ±50fm, stability 10.5pm/°C, meeting strict metrological requirements.
Continuous wide tuning range without jump mode: C-band 1515-1565nm without jump mode tuning, 50nm continuous coverage, suitable for DWDM and full-band testing of fiber optic sensing.
Low noise high linear sweep frequency: Driver circuit low-noise design, sweep frequency linear deviation ±1.5 to ±2GHz, power flatness ±7 to ±10%, ripple ±2%, ensuring consistency of scanning data.
