Characteristic bandwidth: 150MHz, rise time less than 2.33ns, which can meet the measurement requirements of some low-frequency signals. Attenuation ratio: 10:1, the input signal can be attenuated to one tenth of the original value and then sent to the oscilloscope, which is helpful to measure higher voltage signals and improve the resolution and accuracy of measurement. Input impedance: The input resistance is 10MΩ (when terminated with 1MΩ) and the input capacitance is about 15pF. High input resistance and low input capacitance can reduce the load effect of the probe on the circuit under test and make the measurement result closer to the real value. Maximum input voltage: the peak values of DC+AC are 500V(Cat I, mains isolated) and 300V(Cat II, post receptacle mains), which can be used for safe measurement in a certain voltage range. Compensation range: 9-17pF. By adjusting the compensation capacitor, the probe and oscilloscope can achieve better impedance matching and reduce signal distortion.
