凭借业界领先的技术指标性能提高测试吞吐量
通过高级测量功能精确表征被测件的功率曲线
用于功率存储测试应用的完整双象限工作
使用黑匣子记录器跟踪功率事件
内置 APS 通过并联可提供高达 10 kW 的功率，使测试系统能够更灵活地输出功率
Increase test throughput with industry-leading technical metrics
Test speeds up to 100 times faster than standard system power supplies
Command processing speed < 2ms
Fast up and down programming (up to 500 μs)
The measurement speed can be adjusted to achieve the best balance between speed and accuracy
Accurately characterize the power curve of the part under test with advanced measurement functions
Dual voltage and current measurement with digital multimeter precision
Current and voltage high resolution digitizers are suitable for making dynamic measurements
Power, peak power, watt-hour and ampere-hour measurements
Full two-quadrant operation for power storage test applications
It can work continuously and smoothly during the transition between + current and - current
Provides + and - programmable current limits, programmable + and - current waveforms, and automatic downward programming
Full dual-quadrant operation requires the use of the N7909A power consumption unit, and the independent power supply can provide dual-quadrant operation capacity of 10% of the rated current
Track power events using black box recorders
Optional accessories N7908A black box recorder
Power events can be tracked in background mode regardless of when APS power is started
Record measurement data, trigger events, status bits, etc
The built-in APS provides up to 10 kW of power in parallel, allowing for more flexible power output from the test system
Ensure that the current is evenly distributed between parallel power sources
This is achieved through a three-wire connection on the rear panel of the power supply
Ensure that each parallel power supply is able to operate in a predetermined mode (whether CV or CC)
