828B光通讯高速激光波长计专门为密集波分复用DWDM应用研发与优化，工作范围1250nm-1650nm(182-240THz)；精度高达±0.65ppm，测试速率高达1000HZ。
●可测试CW或调制激光，绝对准确度可达±1pm @ 1550nm,
●内置长寿命稳频HeNe激光器实时校准，完全无需人工干预
●可同时检测各通道激光功率。
<p style="margin: 5px 0px; padding: 0px; color: rgb(51, 51, 51); font-family: -apple-system, BlinkMacSystemFont, " sf="" pro="" sc",="" "sf="" text",="" "helvetica="" neue",="" helvetica,="" "pingfang="" "segoe="" ui",="" roboto,="" "hiragino="" sans="" gb",="" arial,="" "microsoft="" yahei="" yahei",="" simsun,="" sans-serif;="" font-size:="" 16px;"=""> ●标配USB2.0和以太网接口，可增配GPIB接口方便用户架构自动检测系统
The 828B optical communication high-speed laser wavemeter is specially developed and optimized for dense wavelength division multiplexing DWDM applications. The operating range is 1250nm-1650nm(182-240thz). Accuracy up to ±0.65ppm, test rate up to 1000HZ.
Product features:
● Can test CW or modulation laser, absolute accuracy up to ±1pm @ 1550nm
● Test range 1250nm-1650nm(182-240thz) covering all optical communication bands
● Built-in long life frequency stabilized HeNe laser real-time calibration, completely without manual intervention
● Test refresh frequency up to 1000Hz
● Can detect the laser power of each channel at the same time
● standard USB2.0 and Ethernet interface, GPIB interface can be added to facilitate the user architecture automatic detection system
