Product Overview:
Create the ultimate multi-fiber cable assembly test station by adding the RD-P remote Head polarity detector to your RLM return loss meter and OSX-ray switch. Now, with a single connection, you can test IL, RL, and polarity for multiple fiber components such as MPO or duplex LC.
Use with our free cable assembly software and save all IL, RL and polarity results together in the XNS database.
The polarity measurement of 12 optical fibers takes only 4 seconds, but more importantly, you do not need to disconnect the device before performing IL/RL tests. The RD-P does not come into physical contact with the connector, so no inspection or cleaning is required and there is no risk of contamination or damage.
Product features:
The polarity is tested with the DUT connection continuously open, then IL/RL is tested
Fast pass/fail results
Most multi-fiber connectors can be measured
Reduce reference complexity
Test results are stored with XNS IL/RL results
