Basic characteristics
• PC-based instrument with touch screen interface; Optional USB keyboard and mouse •
EasyEXPERT software, the instrument offers tests for more than 200 classified applications
• Perform current and voltage (IV) measurements
Perform capacitance and voltage (CV), capacitance and time (Ct), and capacitance and frequency (Cf) measurements
• Perform quasi-static CV (QSCV) measurements
• Features ALWG and voltage monitoring up to 40 V.
Perform fast IV measurements synchronized with the application waveform for accurate transient IV or time domain measurements
Support for front panel classic test measurement modes: single channel scan, multi-channel scan, time sampling, list scan, CV scan and Direct control (GPIB FLEX)
• GUI-based Agilent B2200A and B2201A switch matrix control
• Modular host with 10 module slots and 1 4.2A ground unit
Multiple source/Monitoring unit (SMU) types available: Medium power (MPSMU), High power (HPSMU) and High resolution (HRSMU)
• Provide
Multifrequency Capacitance Measuring Unit (MFCMU) • Available
High Voltage Semiconductor Pulse Generator Unit (HV-SPGU) • Available
Waveform Generator/Rapid Measurement Unit (WGFMU) • High resolution analog-to-Digital converters (ADCs) are available for all installed
SMU• Each installed SMU
There are high speed ADCs on both Sensor and switching Unit (ASU)
Support SMU/AUX path switching •
