250 kHz到3或6 GHz (.01赫兹决议)
-136到17 dBm @ 1 GHZ和10 dBm @ 6 GHZ输出功率
+/-0.5至+/-0.9 dB级精度(> -110 dBm)
-134 dBc/Hz SSB相位噪声@ 20 kHz偏置，1 GHz载波(典型)
增强相位噪声性能(选项UNJ)船舶标准
高稳定性时基:烤箱控制晶体振荡器(OXCO)
AM, FM， ØM和脉冲调制
直流至10mhz调频速率，最大偏差可达8mhz
双内部函数发生器:正弦，正方形，斜坡，三角形，噪声，直流，脉冲，扫正弦，双正弦
步进和列表扫描(频率和功率)
10BaseT LAN和GPIB
SCPI和IVI-COM驱动程序
向后兼容所有ESG信号发生器
250 kHz to 3 or 6 GHz (.01 Hz resolution)
-136 to 17 dBm @ 1 GHZ and 10 dBm @ 6 GHz output power
+/-0.5 to +/-0.9 dB level accuracy (> -110 dBm)
-134 dBc/Hz SSB phase noise @ 20 kHz offset, 1 GHz carrier (typ)
Enhanced phase noise performance (Option UNJ) ships standard
High-stability timebase: oven-controlled crystal oscillator (OXCO)
AM, FM, ØM, and pulse modulation
DC to 10 MHz FM modulation rates, maximum deviations up to 8 MHz
Dual internal function generators: sine, square, ramp, triangle, noise, DC, pulse, swept sine, dual sine
Step and list sweep (frequency and power)
10BaseT LAN and GPIB
SCPI and IVI-COM drivers
Backwards compatible with all ESG signal generators
