产品描述：
R&S FSV30 是一款多功能信号和频谱分析仪，适用于从事射频系统开发、生产、安装和服务的用户。R&S FSV30 是适用于所有通用测量任务的理想仪器——在工作台上、生产中和现场。它为最新的蜂窝和无线标准提供数字调制分析，分析带宽高达 160 MHz，用于对组件、芯片组和基站进行测量。
FSV30 是罗德与施瓦茨公司的 30 GHz 频谱分析仪。频谱分析仪测量已知和未知信号的频谱功率。频谱分析仪收集信息，例如输入信号与其频率相比的幅度。作为频率分析仪，频谱分析仪的主要用途是记录和分析电输入信号以及其他信号的频谱成分。
功能：
频率范围：10 Hz 至 30 GHz
高达 160 MHz 的信号分析带宽
使用基于触摸屏的用户界面 5 GHz 进行方便、直观的操作
0.4 dB 电平测量不确定度高达 7 GHz
–110 dBc (1 Hz) 相位噪声，10 kHz 频率偏移
+15 dBm 三阶截取 (TOI)
1 Hz 带宽中显示的平均噪声电平 (DANL)：–155 dBm at 1 GHz，–147 dBm at 30 GHz；使用 R&S FSV-B24 前置放大器：–162 dBm at 30 GHz
用于相位噪声、噪声系数、矢量信号分析、模拟解调、EMI 诊断的通用测量应用
LTE（包括 LTE-Advanced）、WLAN（包括 IEEE 802.11 AC）、WCDMA/HSPA+、TD-SCDMA、GSM/EDGE、CDMA2000®/1xEV-DO、Bluetooth® 的无线测量应用
频率范围高达 500 GHz，带有谐波混频器
使用可移动固态或硬盘驱动器保持测试数据的机密性
支持的技术；
WLAN 802.11a/b/g/j/p/n/AC
WCDMA / HSPA / HSPA +
3GPP LTE
GSM/EGPRS/EDGE/EDGE演进/VAMOS
CDMA2000® 1xEV-DO
CDMA2000® 1xRTT
TD-SCDMA
AM
FM
PM
Product Overview:
The R&S FSV30 is a versatile signal and spectrum analyzer for users working in the development, production, installation and servicing of RF systems. The R&S FSV30 is the ideal instrument for all general-purpose measurement tasks – on the bench, in production, and in the field. It provides digital modulation analysis for the latest cellular and wireless standards with up to 160 MHz analysis bandwidth for measurements on components, chipsets and base stations.
The FSV30 is a 30 GHz Spectrum Analyzer from Rohde & Schwarz. A spectrum analyzer measures the power of spectrums of known and unknown signals. Spectrum analyzers collect information such as the magnitude of an input signal compared to its frequency. As a frequency analyzer, spectrum analyzers’ main use is to document and analyze electrical input signals as well as spectral compositions of other signals.
Features:
Frequency range: 10 Hz to 30 GHz
Up to 160 MHz signal analysis bandwidth
Convenient, intuitive operation with touchscreen based user interface 5 GHz
0.4 dB level measurement uncertainty up to 7 GHz
–110 dBc (1 Hz) phase noise at 10 kHz frequency offset
+15 dBm third-order intercept (TOI)
Displayed average noise level (DANL) in 1 Hz bandwidth: –155 dBm at 1 GHz, –147 dBm at 30 GHz; with R&S FSV-B24 preamplifier: –162 dBm at 30 GHz
General-purpose measurement applications for phase noise, noise figure, vector signal analysis, analog demodulation, EMI diagnostics
Wireless measurement applications for LTE (including LTE-Advanced), WLAN (including IEEE 802.11 AC), WCDMA/HSPA+, TD-SCDMA, GSM/EDGE, CDMA2000®/1xEV-DO, Bluetooth®
Frequency range up to 500 GHz with harmonics mixers
Keeping test data confidential with removable solid state or hard disk drives
Supported Technologies;
WLAN 802.11a/b/g/j/p/n/AC
WCDMA/HSPA/HSPA+
3GPP LTE
GSM/EGPRS/EDGE/EDGE Evolution/VAMOS
CDMA2000® 1xEV-DO
CDMA2000® 1xRTT
TD-SCDMA
AM
FM
PM
