Product Description:
The ZNH4 is a full dual-port handheld vector network analyzer (VNA) that provides single-port cable and antenna measurements as well as full dual-port S-parameter measurements. The touch-based interface simplifies operations, and the configuration overview menu makes measurement preparation more efficient. The ZNH may be small in form, but it is complete in every detail and offers good performance and all key features.
Maintaining the operation of an RF communication system requires the rapid identification of any defects in the system components. The ZNH is a versatile, handheld vector network analyzer that helps field engineers repair defective components detected in their systems.
The basic version of the ZNH4 handheld vector network analyzer can perform single-port cable and antenna measurements as well as four S-parameter measurements up to 26.5 GHz. By adding power meters, pulse measurements, wave ratios, and wave volume capabilities, ZNH enables field engineers to quickly maintain and restore radar and satellite systems.
Features:
Frequencies range from 30 kHz to 4/8/18/26.5 GHz
Single port cable and antenna measurements using basic instruments
S-parameters (S11, S12, S21, S22) are measured using basic instruments
100 dB (typical value) dynamic range for filter and antenna isolation measurements
