Product Description:
The Agilent N5234B PNA-L series network analyzer is designed for S-parameter and simple nonlinear testing of passive components, amplifiers and inverters. The PNA-L uses the same core firmware as the PNA, achieving the perfect balance between value and performance. PNA-L provides efficiency and flexibility for manufacturing and R&D applications in industries ranging from mobile telecommunications and wireless LAN component production to aerospace and defense.
For passive devices with one or more balanced/differential ports, the Agilent N5234B is an excellent choice for mixed-mode S-parameter measurements without the need to use Barron or Barron. Users can display differential, common-mode, and mixed-mode performance in a variety of trace formats. The measurement parameters include common mode rejection ratio and amplitude and phase unbalance. Supported port configurations include single-ended to balanced and balanced to balanced topologies.
Features:
Perform basic analysis of passive components and simple active devices
For cost-sensitive applications, S-parameters can be accurately measured in frequency ranges up to 43.5 GHz
With excellent cost performance, it can be used for microwave device manufacturing testing
Cost-effective solutions can be configured for signal integrity measurement and material characterization
Multi-touch screens and intuitive user interfaces accelerate analysis of component characteristics
