E36313A可编程直流电源6V/10A和25V/2A三路输出，最大功率160W，可同时查看全部三个通道上的独立电压和电流测量及设置显示，输出数据可分别记录保存，提供了更好的体验和精度，具备SCPI编程程控功能，支持USB、LAN连通，可选GPIB连接
E36313A直流电源 160W 三路输出电源，6V，10A 和 2X 25V，2A
E36313A 三路输出电源能够提供高达 10 A 的大电流。
主要技术指标
低输出噪声——纹波和噪声小于 350 µVrms
精确的编程和回读，精度小于 0.04%
出色的稳定性，线路和负载调节精度达到 0.01%
所有三路输出彼此绝缘，可以独立设置
4 线传感可以提高测量精度
过压和过流器件保护
连通性：USB、LAN（LXI Core）、GPIB（可选）
E36313A programmable DC power supply 6V/10A and 25V/2A three-way output, the maximum power is 160W, and independent voltage and current measurement and setting display on all three channels can be viewed at the same time. The output data can be recorded and saved separately, providing better Experience and precision, with SCPI programming function, support USB, LAN connection, optional GPIB connection
E36313A DC power supply 160W three-way output power supply, 6V, 10A and 2X 25V, 2A
The E36313A triple output power supply can provide a large current up to 10 A.
Main Specifications
Low output noise-ripple and noise are less than 350 µVrms
Accurate programming and readback, accuracy is less than 0.04%
Excellent stability, line and load regulation accuracy reaches 0.01%
All three outputs are insulated from each other and can be set independently
4-wire sensing can improve measurement accuracy
Overvoltage and overcurrent device protection
Connectivity: USB, LAN (LXI Core), GPIB (optional)
